Shelf store with light for warehouse
We are the leading and professional manufacturer of warehouse racking in China. All products
Have detected by SGS, AS4084, RoHS, CE also have passed the ISO9001 quality certification.
All the rack that we produce is customized, We will be happy to give you a quotation upon receipt
Of your detailed requirements.
1. Features: Pallets can be located, accessed and moved individually.
Rapid handling of almost all types of palletised goods.
Infinitely adjustable and offering a wide range of options and components to accommodate specialized needs.
Maximizes space use in any warehouse configuration while retaining optimum product accessibility.
Strength and rigidity prevents compression damage to goods.
Bottom level of pallets can be stored on the floor, lowering structure costs.
2. Load Capacity & Dimension: Loading capacity: 500-4, 000 kgs UDL/beam level.
Height: 1, 000-11, 000mm
Depth: 400-1, 500mm
Length: 1, 500-3, 300mm
Specail sizes also avaiable to specific storage needs.
3. Main Parts Specs: Upright section: 80*60mm, 90*60mm, 100*60mm, 88*68mm, 100*68mm, 110*68mm, 120*68mm, etc.
Box beams section: 80*45mm, 90*45mm, 100*45mm, 110*45mm, 120*45mm, 130*45mm, 140*45mm, etc.
Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components.
4. Material: High-quality steel, Q235
5. Finish: High-quality Powder Coating Finish.
6. Quick Delivery. Within 25 days for ordinary order quantity. Big production capacity allow us in a position to make quick delivery.
7. CertificationSGS and AS4084, RoHS and ISO9001; CE
8. Please inform us the listed questions in your inquiry for quick quotation:
A) The warehouse layout plans
B) The size of racking(length*width*height)
C) How many bays you want
D) How many layers for each bay that you want
E) The loading capacity of each layer
F) Choose steel panel or wooden veneer
G) The RAL color you want
|Product name||warehouse shelf|
|Material||High grade Q235B Steel|
|Specification of rack||Length:1000mm-2700mm |
Standard size:L2000*D600*H2000mm,customized size is available
|warehouse shelf Loading capacity||200-800KG/Layer|
|Surface treatment||Powder Coating Finishing|
|Upright specification||50*45*1.0mm 75*60*1.5mm 90*60*1.5mm|
|Beam Specification||80*45*1.0mm 100*45*1.5mm|
|layer||2-8 layers(as you want)|
|warehouse shelf Features||High capacity storage, easy installation and adjustment, space saving and goods protection Excellent in quality and beautiful in appearance with high quality steel Utilize the space of warehouse effectively Can be adjusted freely by a pitch of 50mm Prompt delivery and shipment Excellent security warehouse rack 7. Static powder coating|
|Application||Warehouse,store,supermarket,4S shop, garage, widely used|
|Main Parts||1) Uprights 2) beams 3) Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components|
|Packing||warehouse rack packed by carton or air bubble film|
Jiangsu NOVA Logistics System Co.,Ltd. It was founded in 1997. After years of development, it has become one of the most well-known racking suppliers and logistics system integration trader in China, being recognized as one of the leading manufacturers in logistics field.Over the past years, we have carried out thousands of big logistics projects, impressed our customers a lot with our quality products and after sales service. We have been pointed as the logistics suppliers for quite a few famous enterprises such as TOYOTA, WAL- MART,SIEMENS,TOSHIBA,BOSH,HONDA,LG and so on.
Pls feel free to contact us.Thanks.
