Automated Storage and Retrieval System (AS RS System)

Automated Storage and Retrieval System (AS/RS) for Warehouse

1. Racking

Design: AS/RS systems typically include pallet racking and drive-in racking, which are both made of a combination of steel and wood panels. These racks have a high load capacity and are used for storing goods in industries such as food, tobacco, electronics, machinery, and defense. Conveyors are used to load and unload items based on instructions from a central computer.

2. Stacker

Design: The stacker in an AS/RS system has a double upright structure that is stable and reliable. It is equipped with vector frequency conversion drive and encoder position control, as well as mechanical and electronic safety features to ensure safe operation. The system uses all-way tracing technology for information transfer and imported electric components. It has a user-friendly touch screen interface for easy operation and can be controlled manually, semi-automatically, automatically, or in conjunction with other logistics equipment.

3. Transportation System

Design Element: The transportation system is typically installed at the front or rear of a warehouse to move goods from one place to another, connecting the tasks performed by forklifts and stackers. It utilizes either a rolling conveyor or chain conveyor, along with lifts, rotating devices, and other machinery.

4. Management System

Design Element: By interfacing with Warehouse Management System (WMS) and Equipment Control System (ECS) using OPC protocol and PROFIBUS bus network, the Siemens S7-300 controller can independently operate all conveyors, facilitating the automatic movement of goods.

Please see the attached diagram for more information on the transportation system.

5. Warehouse Management System Components

Components of WMS System: Network structure, server, RF server, management and monitoring computers, RF base station, and RF terminals for goods in/out warehouse.

Software of WMS System:

Operating system: WINDOW 2000X SERVER

Database: MS SQL SERVER 2000X

Warehouse management software: WMS

Equipment control software: ECS

Barcode management software: RFS

6. Additional Equipment

Additional equipment includes transfer carts, rail carts, operating room tables, automated guided vehicles, automated picking systems, electronic labels, pallet lifts, and more.
