Blue Frame and Orange Beam Pallet Racking with Ce Certificated

Quantity:
Inquire Add to Basket

Product Description

Selective Pallet Racking:

Racking is taken as a suitable and economical storage solution:

1. All the layers can be fix at any height only if it's times of 75mm, user will adjust different height for various pallet storage;

2. We supply quite big sections of upright to suit special needs;

3. Standard and special dimensions are both available, you just put forward your requirement and we design, we give the solutions;

4. Epoxy powder coated and galvanized surface treamment to prevent against corruption;

5. Pitch is with 75mm and 76.2mm(3''), compatible with European top brands like Dexion, Schaefer, etc.

Specification:

1. Upright: NH1 TYPE (Upright 80), NH2A TYPE(Upright 90A), NH2B TYPE(Upright 90B), NH3 TYPE(Upright 100), NH4 TYPE(upright 120), NH5 TYPE(upright 140), NH6 TYPE(Upright 160) or customized by clients.

2. Beams are divided into Box beams and Step beams.

3. Sectional sizes of box beams include: Y80, Y100, Y110, Y120, Y140, Y160.

4. Sectional sizes of step beams include: P100,P125

5. Pallet support bar: Regular type and cut-in adjustable types.

Product name warehouse shelf
Material High grade Q235B Steel
Specification of rack Length:1000mm-2700mm
Depth:500mm-1200mm
Height:2000mm-5000mm
Standard size:L2000*D600*H2000mm,customized size is available
warehouse shelf Loading capacity 200-800KG/Layer
Surface treatment Powder Coating Finishing
Upright specification 50*45*1.0mm 75*60*1.5mm 90*60*1.5mm
Beam Specification 80*45*1.0mm 100*45*1.5mm
layer 2-8 layers(as you want)
warehouse shelf Features High capacity storage, easy installation and adjustment, space saving and goods protection Excellent in quality and beautiful in appearance with high quality steel Utilize the space of warehouse effectively Can be adjusted freely by a pitch of 50mm Prompt delivery and shipment Excellent security warehouse rack 7. Static powder coating
Application Warehouse,store,supermarket,4S shop, garage, widely used
Main Parts 1) Uprights 2) beams 3) Horizontal & diagonal braces, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components
Packing warehouse rack packed by carton or air bubble film

We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.

Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window, we all help you out at the earliest.

Project Cases:

Blue Frame and Orange Beam Pallet Racking with Ce CertificatedBlue Frame and Orange Beam Pallet Racking with Ce Certificated

Sales Centre:

Blue Frame and Orange Beam Pallet Racking with Ce Certificated

Cooperation Partners:

Blue Frame and Orange Beam Pallet Racking with Ce Certificated
