Structure:
1. Cut-in composite structure, standard cut-in units; Assembling and dismantling are simple and quick, high-strength steel panel by continuous punching and rolling; Shelving depth can be adjusted freely; Support bars are fixed to the bottom of the panel in order to reinforce the loading capacity, and there are filters in the front of the panel for use of reinforcing, making it look good.
2. The storage space of each layer can be divided freely by fixing separators to the holes on panel surface; Height of each level can be adjusted every 50mm easily, square upright, the capacity of each layer can be up to 500kg, widely used in every walk of life.
3. NM1A shelving is most suitable for building Mezzanine.
| Length (mm) | Capacity of each layer(kg) |
| 900 | 1200 | 1500 | 1800 |
| 480 | 600 | 560 | 360 | 240 |
| 620 | 600 | 620 | 380 | 260 |
| 910 | 600 | 600 | 600 | 390 |
| 940 | 600 | 600 | 600 | 480 |
| 1220 | 600 | 600 | 600 | 520 |
| Size of upright(mm) | 55*55*1.5,Pitch=50, H=1.5,1.8,2.0,2.4,3,4.8(m) |
AFQ:
| 1. What makes you different with others? |
| 1) Our Excellent Service |
| For a quick, no hassle quote just send email to us |
| We promise to reply with a price within 24 hours - sometimes even within the hour. |
| If you need an advice, just call our export office at 0086-25-51873961, we will answer your questions immediately. |
| 2)Our quick manufacturing time |
| For Normal orders, we will promise to produce within 15 days. |
| As a manufactory, we can essure the delivery time according to the formal contract. |
| 3)Our Special Export Design |
| We pay very much attention to the export packages. We have plastic clips on the beams to protect the beams from surface damage in the transportation, We have got the whole uprights wrapped with transparent plastic film. |
| 4)Our Warranty Time |
| The High Standards in the Design and Manufacturing ensure us to support the products with a 10-Year Warranty Time for your normal use, it is the Longest Manufacturer's Warranty ! |
| 2. What is delivery times? |
| This depends on the product. Typically standard products are delivered within 20 days. |
| The delivery time of the special products is according to the time of setting up of the tooling. |
| 3.What is the term of payment? |
| 1) T/T payment. 2) LC |
| 4. May I know the status of my order? |
| Yes .We will send you information and photos at different production stage of your order. You will get the latest information in time. |
| 5. Are samples available? |
| Yes, we can send some sections of samples for your reference by express. |
We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window, we all help you out at the earliest.
