Product Description
Structural Feature:
1.VNA pallet racking refers to the pallet racking system for which three-direction forklifts are used.
2.The major difference of VNA racking from regular pallet racking is that the width of the VNA racking aisle (usually 1600-2000mm) is much narrower than that of the regular pallet racking system, which makes better use of storage space by 20%. 3.Guide rails are needed to be fixed at the two sides of the aisle to guide the forklift.
Model: NH heavy duty VNA racking
Specification :
UPRINGHT: NH1 TYPE (80 TYPE),NH2A TYPE(90A TYPE),NH2B TYPE(90B TYPE),NH3 TYPE(100 TYPE)
NH4 TYPE(120 TYPE),NH5 TYPE(140 TYPE),NH6 TYPE(160 TYPE)
The non-standard ones can be customized based on clients' requirements.
Beams are divided into Box beams and Step beams
Sectional sizes of box beams include: Y80,Y100,Y110,Y120,Y140,Y160
Sectional sizes of step beams include: P80,P100,P125
| Frame | Height (2-13m) | Depth (600-1,400mm) |
| Upright section: 80x60; 90 x 70; 100 x 65; 120 x87mm | ||
| Thickness: 2.0/2.3/2.5/3.0mm | ||
| Beam | Length (1200-4000mm) , popular size: 2300,2500,2700,3200,3600mm | |
| Beam section: 80 x 50; 100 x 50;110x50; 120 x 50; 140 x 50mm | ||
| Thickness: 1.4--1.5mm | ||
| Load capacity | 1-4Tons/Layer | |
| Others | Pitch: 75mm,76.2mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts & nuts, base plate, etc) - Packing: stretch film & carton - Surface treatment: powder coated, galvanization - Production capacity: 3000T/month - Main market: exported more than 40countries, such as AU, PH, SG, UK, INDIA and etc. - Available in various colors/specifications/sizes | |
ARQ:
| 1. What makes you different with others? | ||||
| 1) Our Excellent Service | ||||
| For a quick, no hassle quote just send email to us | ||||
| We promise to reply with a price within 24 hours - sometimes even within the hour. | ||||
| If you need an advice, just call our export office at 0086-25-51873961, we will answer your questions immediately. | ||||
| 2)Our quick manufacturing time | ||||
| For Normal orders, we will promise to produce within 15 days. | ||||
| As a manufactory, we can essure the delivery time according to the formal contract. | ||||
| 3)Our Special Export Design | ||||
| We pay very much attention to the export packages. We have plastic clips on the beams to protect the beams from surface damage in the transportation, We have got the whole uprights wrapped with transparent plastic film. | ||||
| 4)Our Warranty Time | ||||
| The High Standards in the Design and Manufacturing ensure us to support the products with a 10-Year Warranty Time for your normal use, it is the Longest Manufacturer's Warranty ! | ||||
| 2. What is delivery times? | ||||
| This depends on the product. Typically standard products are delivered within 20 days. | ||||
| The delivery time of the special products is according to the time of setting up of the tooling. | ||||
| 3.What is the term of payment? | ||||
| 1) T/T payment. 2) LC | ||||
| 4. May I know the status of my order? | ||||
| Yes .We will send you information and photos at different production stage of your order. You will get the latest information in time. | ||||
| 5. Are samples available? | ||||
| Yes, we can send some sections of samples for your reference by express. |
We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.
Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window or add my Skype, we all help you out at the earliest.
