High Density Steel Pallet Racking for Warehouse Storage

Quantity:



Inquire Add to Basket

Product Description

Product Description

^{Pallet rack:
Pallet racking is a versatile system with unsurpassed adaptability for many types Of industries. Our system allows you to easily store pallets, or by using wire Decking you can store anything. It is engineered for maximum strength and value.

Pallet rack is comprised of three components: Upright frame, beam, wire decking

1. Upright frame:
All upright frames use rectangular tubing for frame bracing. The closed box section Is superior to open channels, round tubing, rods or angle bracing. Independent Triangulation is achieved by welding diagonals directly to columns, not to the Horizontals. Rectangular tubing and independent triangulation are two important Features that add up to years of durable and dependable service.

2. Beam:
Beams use a minimum of three load bearing studs on each end plate to transfer loads Safely to upright columns. These studs, in conjunction with teardrop keyholes, Work together to draw the end plates securely against the upright columns, create A tight connection that reduces rotation and sway. Drive-in/drive-thru support Arms, 6" step beams, and mezzanine support beams all use four load bearing studs For added safety.

Shelving's rack systems offer:
1) Standard sizes to fit most racks
2) Fully utilize virtual space
3) Suitable for storing all kinds of goods
4) The bearing capacity per shelf of such rack maybe 4, 500kg
5) Durable finish, clean appearance, fire resistant

We can also supply the size specifications as per your request}

^Others:
^Design	^{professional design for your requirment:include choose the correct type for you,CAD drawing}
^Price	^{direct Manufacture price,according to your quantity,payment}
^Package	^{standard export package}
^Payment	^{30%prepaid T/T,L/C at sight FOB,CNF,CIF}
^Shippment	^{FOB NANJING,FOB SHANGHAI}
	^{CNF/CIF destination port}
^{Quick Delivery.}	^{Within 25 days for ordinary order quantity. Big production capacity allow us in a position to make quick delivery.}
^{Certification}	^{CE:if you need,can make for you}

^{Route:
Our office and factory are located in Nanjing, Jiangsu Province, China
1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;
2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in Nanjing South Railway Station.
All our clients, from domestic or abroad, are warmly welcome to visit us!}

^Frame	^{Height (2-13m)}	^{Depth (600-1,400mm)}
	^{Upright section: 80x60; 90 x 70; 100 x 65; 120 x87mm}
	^{Thickness: 2.0/2.3/2.5/3.0mm}
^Beam	^{Length (1200-4000mm) , popular size: 2300,2500,2700,3200,3600mm}
	^{Beam section: 80 x 50; 100 x 50;110x50; 120 x 50; 140 x 50mm}
	^{Thickness: 1.4--1.5mm}
^{Load capacity}	^{1-4Tons/Layer}
^Others	^{Pitch: 75mm,76.2mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts & nuts, base plate, etc) - Packing: stretch film & carton - Surface treatment: powder coated, galvanization - Production capacity: 3000T/month - Main market: exported more than 40countries, such as AU, PH, SG, UK, INDIA and etc. - Available in various colors/specifications/sizes}

^{We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.

Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window, we all help you out at the earliest.}
