Shelf Radio Shuttle Pallet Racking Shelves Remote Pallet Runner Shelf Radio Shuttle Racking System

Radio shuttle rack is the combination of the drive in rack and pallet runner, which can reach the result of semi-automatic storage. According to goods pick-up location, it has first in frst out(FIFO) and last in frst out (LIFO).
  • NH
  • NOVA
  • 73089000
Quantity:

Product Description





 Radio Shuttle Pallet Racking


Radio shuttle rack is the combination of the drive in rack and pallet runner, which can reach the result of semi-automatic storage. According to goods pick-up location, it has first in frst out(FIFO) and last in frst out (LIFO).


The advantage of shuttle pallet rack

— High density storage style, high warehouse utilization rate
— High work efficiency, greatly reduce operating time
— Operating flexibility, the access of goods can be FIFO, can also be FILO
— And good safety, reduce damage, improve safety productivity


The working principle of shuttle pallet rack

— Inventory: The goods are put on the front end of the storage tunnels by the forklift truck, through radio remote control shuttles, can carry pallets of goods in track operation;
— Pick: radio remote control shuttle carries the pallet from the farthest end of the storage tunnel to the nearest end of the racking system, put down the pallet from the racking system by the forklift truck;
— Mobile shuttle : The shuttle can be place in different storage tunnel by the forklift, several storage tunnels can share a shuttle. The quantity of shuttle is depend on the depth of the storage tunnel, total of goods, shipping quantity, shipment frequency and other factors.


Shuttle rack technical parameters

— Load: 1000~1500kg
— Speed: 0.7-0.9 M / sec(unload)
— Speed:0.6-0.8 M / sec(load)
— Power unit: lithium manganese battery
— Rated voltage: 26 V
— Battery: time greater than 8 hours
— Sensing range: remote sensing range within 50 meters



Hfb3d4d10471343d4bf75264b640f4b24u




Technology Specifications of pallet runner





Loading Capacity Suggested 1000kgs 1200kgs
Rated Voltage 26V
Loading Speed without pallet 0.7-0.9m/s
Working time for battery duration over 8 hours
Loading Speed with pallets 0.6- 0.8m/s
Range of Remote Radio Controller is 50 meters
Power Unit  Lithium Battery
