Product Description
VNA Stacking Lift High Bay Racking System
Advantages of NOVA:
1) Free but expert advice & professional storage solutions satisfying specific storage needs.
2) Strict order execution: Strict quality control, Rapid delivery.
3) Within 20 days for ordinary order quantity.
4) Free small Samples available.
VNA pallet racking:
We are specialist in the design and installation of Very Narrow Aisle (VNA) pallet racking systems:
1. The height is up to 20000mm, the width is 1500-3500mm and the depth is 800-1500mm
2. Very Narrow Aisle ( VNA ) racking is similar to Selective racking but decreases the aisle widths more than 50% for greater storage capacity;
3. Used majorly for high volume and traffic areas by increasing height of upights;
4. NOVA VNA Racking is your best choice for the optimal use of floor space and anywhere that has a narrow aisle access and high density storage needs;
5. This type of racking is operated with "very narrow aisle" trucks, and ground guided rail through the aisle allows faster and more safe operation.
6. Maximizes storage potential.
Frame | Height (2-13m) | Depth (600-1,400mm) |
Upright section: 80x60; 90 x 70; 100 x 65; 120 x87mm | ||
Thickness: 2.0/2.3/2.5/3.0mm | ||
Beam | Length (1200-4000mm) , popular size: 2300,2500,2700,3200,3600mm | |
Beam section: 80 x 50; 100 x 50;110x50; 120 x 50; 140 x 50mm | ||
Thickness: 1.4--1.5mm | ||
Load capacity | 1-4Tons/Layer | |
Others | Pitch: 75mm,76.2mm - Delivery time: 14-20days - Payment term. T/T or L/C at sight - Necessary accessories: free(bolts & nuts, base plate, etc) - Packing: stretch film & carton - Surface treatment: powder coated, galvanization - Production capacity: 3000T/month - Main market: exported more than 40countries, such as AU, PH, SG, UK, INDIA and etc. - Available in various colors/specifications/sizes |
China : 8 #Boqiao street, Binjiang development zone, Nanjing, Jiangsu, China
US: 3702 W Sample Street,South Bend,Indiana,46619
Our company is a manufacturer of warehouse racks and automation warehouse system. During the past 20+ years, our company has been dedicated to planning, designing, producing and installing rack system and AS/RS system.
